Bhavesh PTFE Lined Pipe, based in Hyderabad, is a reputed manufacturer and exporter of PTFE, FEP, and PFA lined reducers designed to function in harsh industrial conditions. Our PTFE Lined Reducers are developed to tackle aggressive chemicals and temperatures with long-term, stable performance. Constructed with robust materials and smooth internal lining. These fittings are utilized to control flow between various pipe sizes with minimal pressure loss. Offered in customizable configurations, they can be used for a variety of industrial process applications.
PTFE Lined Reducers are pipe fittings employed to join pipes of varying diameters, providing safe and efficient flow in corrosive or high-purity systems. The PTFE lining on the inside forms a non-reactive barrier that shields the system from chemical damage and contamination. These reducers are utilized in many industrial applications. Such as chemical processing, pharma, food manufacturing and water treatment. The two varieties that can be accessed are concentric reducers, which possess aligned centerlines in vertical installations, and eccentric reducers, whose centerlines are different perfect for horizontal installations. Both facilitate the preservation of flow integrity, minimize turbulence, and enhance overall system reliability.
Size : 25 NB to 300 NB
Outer body : ASTM A 395 Gr 60-40-18
Flange Connection : ANSI B 16.5
Face to Face : ANSI B 16.10
Spark Test : 15 KVA
Hydro Test : at 29.8 kg/cm2
FEP- Max Temp : 180° C
PP Max Temp : 100° C
PFA Max Temp : 200° C
Bhavesh PTFE Lined Pipe is a leading supplier of PTFE Lined Reducer in Hyderabad, Telangana, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
| NB | L | FLG. | RF | PCD | App. | App. | LINER THK | N x M | WEIGHTS | |
|---|---|---|---|---|---|---|---|---|---|---|
| O / D | O / D | T1 | T1 | Vaccume (T) | Non Vacc (T) | (kg/piece) | ||||
| 1/2″ | —- | 89 | 35.1 | 60.5 | 14.2 | 24.2 | 3.0 | 3.0 | 4 x 1/2″ | 4 |
| 3/4″ | —- | 98 | 42.9 | 69.9 | 15.7 | 27.7 | 3.0 | 3.0 | 4 x 1/2″ | 3.5 |
| 1″ | 89 | 108 | 50.8 | 79.2 | 17.2 | 29.2 | 4.0 | 3.0 | 4 x 1/2″ | 5.5 |
| 1 1/4″ | 95 | 118 | 63.5 | 88.9 | 18.7 | 30.2 | 4.0 | 3.0 | 4 x 1/2″ | 7.7 |
| 1 1/2″ | 102 | 127 | 73.2 | 98.6 | 20.5 | 32.5 | 4.0 | 3.0 | 4 x 1/2″ | 8.7 |
| 2″ | 114 | 152 | 91.9 | 120.7 | 22.1 | 37.1 | 4.0 | 3.0 | 4 x 1/2″ | 14.0 |
| 2 1/2″ | 127 | 178 | 104.6 | 139.7 | 25.4 | 40.4 | 4.0 | 3.0 | 4 x 5/8″ | 20.6 |
| 3″ | 140 | 191 | 127.0 | 152.4 | 27.9 | 42.9 | 4.0 | 3.0 | 4 x 5/8″ | 24.8 |
| 4″ | 165 | 229 | 157.2 | 190.5 | 28.9 | 43.9 | 4.5 | 3.0 | 8 x 5/8″ | 39.1 |
| 5″ | 190 | 254 | 185.7 | 215.9 | 28.9 | 43.9 | 6.0 | 5.0 | 8 x 3/4″ | 68.8 |
| 6″ | 203 | 279 | 215.9 | 241.3 | 30.4 | 45.4 | 6.0 | 5.0 | 8 x 3/4″ | 79.5 |
| 8″ | 229 | 343 | 269.7 | 298.5 | 33.4 | 48.4 | 6.0 | 5.0 | 8 x 3/4″ | 99.0 |
| 10″ | 280 | 406 | 323.9 | 362.0 | 35.7 | 50.7 | 7.5 | 5.0 | 12 x 7/8″ | 160.0 |
| 12″ | 305 | 483 | 381.0 | 431.8 | 37.8 | 52.8 | 7.5 | 5.0 | 12 x 7/8″ | 280.0 |
Withstands harsh acids and solvents.
Prevents fluid leakage at joints.
Suitable for extreme process heat.
Tailored to fit system specifications.
Both concentric (aligned centerlines) and eccentric (offset centerlines) types are available to suit different flow conditions and installation layouts.
These fittings are commonly used in chemical plants, pharmaceutical manufacturing, food and beverage processing, and water treatment facilities.
Yes, custom dimensions and configurations are available to match specific piping systems and application needs.
PTFE is widely used for its broad chemical resistance; FEP is more easily formed and processed; PFA provides superior temperature tolerance and enhanced flexibility.
A lined reducer connects pipes of different diameters while offering high corrosion resistance in environments with harsh or reactive chemicals.
